Nickel-based
Nickel-based filler material is a brazing filler composed of nickel as the matrix, supplemented with low-melting-point elements (such as boron, silicon, phosphorus, etc.) and strengthening elements (such as chromium, cobalt, molybdenum, tungsten, iron, etc.)
Nickel-based brazing filler metal is a brazing material composed of nickel as the base matrix, combined with low-melting elements such as boron, silicon, and phosphorus, as well as strengthening elements like chromium, cobalt, molybdenum, tungsten, and iron.
BNi-2 nickel-based brazing filler metal
BNi-2 is one of the most widely used nickel-based brazing alloys, characterized by a low melting temperature and excellent wettability and fluidity. During brazing, the base metal grains do not grow, thereby minimizing the risk of degraded component performance.
Inconel 625 nickel-based powder
1. High-Temperature and Corrosion-Resistant Properties: Temperature resistance range: –200°C to 1000°C; excellent oxidation and sulfidation resistance; resistant to seawater, chlorides, and acidic media, making it suitable for marine and chemical‑process applications. 2. Superior Processability: High sphericity (≥98%), low oxygen content (≤0.1%), and excellent flowability, minimizing defects in 3D printing; strong adhesion to substrates, enabling the fabrication of high‑precision, complex structures. 3. High Strength and Toughness: Tensile strength at room temperature ≥ 900 MPa, with outstanding mechanical properties even at elevated temperatures.
1. High-Temperature Performance Applicable temperature range: -250°C to 700°C, resistant to high-temperature oxidation, creep, and sulfide corrosion. Strength is significantly improved after age hardening (room temperature tensile strength ≥ 1300 MPa). 2. Corrosion Resistance Resistant to acids, alkalis, chlorides, and seawater corrosion, suitable for chemical, marine, and nuclear industries. 3. Process Compatibility High sphericity (≥97%), low oxygen content (≤0.1%), excellent fluidity, compatible with additive manufacturing processes such as SLM (Selective Laser Melting) and EBM (Electron Beam Melting). No tendency for cracking after welding, supports the precision forming of complex structures.
High purity, high hardness, wear resistance and corrosion resistance, low friction coefficient, excellent self-melting, wettability and spray welding, high sphericity, low oxygen, smooth surface, uniform particle size distribution, excellent flow properti
Strong corrosion resistance (resistance to oxidizing solutions containing chloride ions), properties of excellent high temperature performance, high strength, good oxidation resistance and mechanical performance
1. High sphericity: Sphericity ≥ 95%, with excellent flowability, suitable for precision spraying and 3D printing. 2. High purity: Nickel content ≥ 99.8%, oxygen content ≤ 0.2%, ensuring stable material performance. 3. Controllable particle size: Standard particle size 10–45 μm (customization available from 5 to 100 μm). 4. Low oxidizability: Packaged in an inert atmosphere, offering strong oxidation resistance and long-term storage stability. 5. Wide range of applications: Compatible with conductive pastes, MIM (metal injection molding), battery electrodes, and other processes.
Electrolytic refining, high purity, excellent electrical conductivity, corrosion resistance and figurability
1. Ultra-high purity (≥99.8%), with stable and reliable performance. 2. Uniform particle size distribution and excellent flowability, compatible with a wide range of forming processes. 3. Low oxygen content (≤0.15%), minimizing the risk of oxidation during sintering. 4. Customizable particle size, morphology, and surface treatments (e.g., antioxidant coatings).
The carbon and boron in BNi-1 brazing filler metal can diffuse into the base material during the brazing process, thereby increasing the remelting temperature of the brazed joint. This filler metal has a high chromium content, so the brazed joint exhibits good high-temperature performance and is suitable for components subjected to high stress at elevated temperatures.
BNi-5 brazing filler metal does not contain boron, significantly reducing its effect compared to the base material. It is suitable for brazing thin parts. This filler metal has a high melting temperature and brazing temperature. Due to its high chromium content, the joint's high-temperature strength and oxidation resistance are comparable to BNi-1.
